LiveKit Agents: An architectural breakdown of the framework for building real-time AI agents

Introduction: From hype to engineering reality

Let’s be honest, we’ve all seen this anti-pattern. A team gets a task to build a voice AI assistant. With full enthusiasm, they grab WebRTC to handle media streams. Then they manually write code that chops audio into chunks and sends them to an STT service like Deepgram. After waiting for the transcription, they call GPT-4 over a REST API, get a text response, run it through a TTS service, and then try to somehow synchronize everything while streaming the audio back to the client.

In my experience, after two months of this work the team ends up not with a product but with a fragile monster. The system has a 3–4 second delay, crashes from any small interruption from the user and becomes a nightmare to debug and maintain. This approach is a straight path into huge technical debt.

The problem is not the engineers’ skills. The problem is fundamental and has a technical name: impedance mismatch. We try to connect two very different worlds: the streaming, stateful world of WebRTC, where session state and continuous data matter, and the transactional, mostly stateless world of modern AI APIs. Trying to glue them together by hand is like trying to connect a water pipe to a high-voltage cable.

This is exactly the core problem LiveKit Agents was created to solve. I came to the conclusion that it is not just another SDK or bot builder, but an elegant architectural solution that works as an adapter between these two worlds. The goal of this article is to give you, as technical leaders, a complete analysis of this framework so you can make an informed decision about using it and clearly see both the benefits and the risks with hidden costs.

Section 1. The foundation: why LiveKit Agents is an architectural solution, not just an SDK

To understand the real power of LiveKit Agents, you need to make one key mental shift: stop thinking of an AI agent as an external service that you call through an API.

1.1. A stateful agent as a full session participant

The key innovation of the framework is that the AI agent becomes a full participant in the WebRTC session, just like the human user. In practice this means the agent connects to the same LiveKit “room” as a server-side WebRTC client. It receives audio and video streams in real time, can send its own streams, and most importantly has full access to the session state.

This completely changes the paradigm. Instead of a long chain Client → Backend → AI API → Backend → Client, we get an elegant model where the agent and the user interact directly inside one communication protocol. The impedance problem disappears because the agent starts “speaking” the native language of real-time communication.

1.2. The “Worker-Job” architecture: resilience and scalability for enterprise systems

At the system level, this concept is implemented through the "Worker-Job" architecture. When an agent needs to log in to a session, LiveKit creates an isolated task (Job). This task is picked up by one of the available workers (Worker), who runs the agent’s logic.

From an architectural point of view, this model is brilliant in its simplicity and efficiency:

• Isolation of sessions: Each “Job” is fully isolated. If one agent crashes because of a code error or an external API failure, it does not affect any other agents running on the same or neighboring “Workers.”
• Horizontal scaling: Need to handle 10,000 simultaneous sessions? Just start more “Worker” instances. Scaling becomes a simple task that any DevOps engineer understands.
• Fault tolerance: If a “Worker” fails, the “Job” can be automatically restarted on another available executor.

And this is not just theory. In my experience, architectures like this prove their stability in real production. My recommendation is to always look for patterns like these when choosing infrastructure solutions. It is also worth noting that a very similar model is used by OpenAI to run the voice mode in ChatGPT. This is a strong social proof that answers most questions about whether this approach can handle enterprise-level workloads.

Section 2. The anatomy of natural dialogue: a decision matrix for the Voice AI Pipeline

So now we understand how the agent lives inside the system. Let’s look at what makes it capable of holding a natural dialogue. Building a voice pipeline (Voice AI Pipeline) is an art of compromise. There is no single “best” STT, LLM or TTS service. There is only the best service for your specific use case.

I have come to the conclusion that instead of simply listing technologies, it is much more useful to think in terms of a “decision matrix,” where we consciously balance three key parameters: Latency vs. Quality vs. Cost.

Below is an example of such a comparison table based on my own experience. It’s not an exhaustive list but rather a template for your own analysis.

2.3. The Secrets of Low Latency

LiveKit Agents provides built-in mechanisms that make it possible to achieve the feeling of a “live” dialog. It’s important to understand how these mechanisms work:

• Interruptions: The user can interrupt the agent at any moment, and the framework will immediately stop response generation and switch back to listening. This is a fundamental requirement for natural interaction.
• Preemptive Synthesis: As soon as the LLM produces the first few words of its response, the framework can already begin synthesizing them into speech and sending them to the user, without waiting for the full answer. This dramatically reduces perceived latency.
• Semantic Turn Detection: Instead of waiting for an artificial pause in the user’s speech, the framework can analyze the semantics of what was said and pass the transcription to the LLM as soon as the phrase appears complete.

In my experience, the competent use of these three techniques is the key to creating an AI conversational partner that feels truly alive.

Section 3. From Conversationalist to Operator: Turning AI into an Agent

Conversation is great, but real business value emerges when the agent can take action: transfer a call, look up information in a database, place an order. LiveKit Agents addresses this through an elegant implementation of the Function Calling concept.

3.1. A Practical Example: Giving the Agent “Hands”

Instead of a thousand words, let's look at the pseudocode fragment we agreed on. Imagine that we are writing an agent for a call center.

# Demonstration of Function Calling in LiveKit Agents

import asyncio
from livekit.agents import function_tool
from livekit.plugins import openai


class CallCenterAgent:
    def __init__(self):
        self.llm = openai.LLM(model="gpt-4o")

    @function_tool
    async def transfer_call(self, agent_id: int, reason: str):
        """
        Transfers the current call to a human operator.

        Use this function when the user explicitly asks to speak with a human
        or when their issue requires a specialist's intervention.

        :param agent_id: A unique identifier of the operator to whom the call
                         should be transferred.
        :param reason: A short transfer reason that the operator will see
                       in the system.
        """
        print(f"Initiating call transfer to operator {agent_id} for reason: {reason}")
        # Here will be the actual logic for integration with your SIP gateway
        # or a CRM system for the actual call transfer.
        await asyncio.sleep(1)  # Simulation of an asynchronous operation
        return f"Status: Transfer to operator {agent_id} initiated."

What’s happening here? The @function_tool decorator does all the magic. LiveKit Agents automatically takes the function name (transfer_call), its parameters (agent_id, reason), their types, and most importantly its docstring, and turns this into a tool description that the LLM can understand.

When the user says, “Connect me to operator 25, I want to discuss my bill,” the LLM understands that it should call this exact function with the appropriate arguments. In my view, this is an incredibly elegant solution that turns documentation writing into part of the functional logic.

3.2. Multi-Agent Handoffs: Decomposing Complex Logic

For complex scenarios, I strongly recommend using the Multi-Agent Handoffs pattern. Instead of creating one monolithic agent that can do everything, we create several narrowly specialized agents and pass control between them. In essence, this is an implementation of a classic Finite State Machine (FSM), where each agent represents a single state.

A typical chain for customer service might look like this:

• Greeting Agent: Welcomes the customer and identifies the language.
• Data Collection Agent: Collects basic information (order number, name).
• Verification Agent: Verifies the information in the database.
• Problem Solving Agent: The main agent that solves the issue.
• Handoff Agent: Transfers to a human if the problem remains unresolved.

This approach not only simplifies development and testing but also allows for more flexible control over logic and cost — using cheaper LLMs for simple tasks and more powerful ones for complex ones.

Section 4. CTO Checklist: Risk Analysis and a Production Template

Adopting a new technology is always more than just writing code. For managers, it’s important to understand the full picture. Let’s walk through the key production aspects.

4.1. Real Total Cost of Ownership (TCO)

Don’t be misled by the apparent simplicity. The TCO for systems built on LiveKit Agents consists of:

• API costs: Expenses for STT, LLM, and TTS can grow quickly as load increases.
• Infrastructure costs: Workers are compute resources, often requiring GPUs, which are not cheap.
• Expertise costs: Professionals capable of building, tuning, and maintaining such systems are rare and expensive.

4.2. Observability and Security

Debugging a distributed real-time system is a non-trivial task. From day one, you must think about observability. Security is also critical, especially if you work with sensitive data (for example, in telemedicine), which raises compliance requirements such as GDPR and HIPAA.

4.3. Vendor Lock-in Risk

Although the LiveKit Agents framework is open source, it inevitably ties you to the LiveKit ecosystem. This is a strategic risk that must be acknowledged. Migrating to another platform in the future will come with significant costs.

4.4. My Recommendation - A “Day 1” Architectural Template

To minimize these risks and lay the right foundation, my recommendation for a production deployment is as follows:

Deployment: Without hesitation, deploy your workers on Kubernetes. Configure a Horizontal Pod Autoscaler (HPA) that automatically scales the number of workers based on load (for example, CPU/GPU utilization or the number of active jobs). This allows you to manage infrastructure costs efficiently.

Observability: Integrate OpenTelemetry from the very beginning. Do not postpone this. Your agents must send structured logs, metrics, and most importantly distributed traces to a system like Datadog, Grafana Tempo, or Jaeger. This is the only way to understand why a particular dialogue went wrong.

Security: Never store API keys for OpenAI, Deepgram, or other services in code or environment variables. Use dedicated secret-management systems such as HashiCorp Vault or cloud-provider equivalents (AWS Secrets Manager, Google Secret Manager). This should be a standard for any production system.

Conclusion: A Strategic Investment, Not a “Silver Bullet”

To sum up, I’ve come to the conclusion that LiveKit Agents is not a “silver bullet” and not a tool for quickly prototyping chatbots. It is a powerful strategic infrastructure investment for companies that are serious about building complex real-time AI agents.

The framework will be an ideal solution if:

• Your product requires natural, stateful interaction with low latency.
• You plan to scale to thousands of simultaneous sessions.
• You are ready to invest in proper architecture and production infrastructure.


It will likely be excessive if:

• You need a simple text chatbot for a website.
• Your task can be solved with straightforward stateless AI API calls.


The decision to adopt LiveKit Agents should be based on a clear assessment of its advantages - such as drastically accelerated development and strong standardization, and your readiness to support enterprise-grade operational infrastructure. With the right choice, you’ll be building your product on a solid foundation rather than a fragile stack of disconnected APIs.
